Woodward 8280-419 Digital Speed Control for Single-Engine Marine Propulsion features Remote Speed/Load Settings, 2 Local Operating Network Channels, and Configurable Update Time Groups of 10 to 80 milliseconds.

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a 8280-419 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8280-419
  • SKU: 8280419WO
  • Manufacturer: Woodward
  • Series: 723 and 723PLUS Digital Control

8280-419 Technical Specifications

Part Number 8280-419
Series 723PLUS Control/Marine
Manufacturer Woodward
Operating Temperature -40 to +70 °C (-40 to +158 °F)
Storage Temperature -55 to +105 °C (-67 to +221 °F)
Model Single Engine Marine Propulsion
Dimensions (cm) W41.275 x L29.21 x H6.0325
Weight 2.95kg before packaging
Enclosure Type Metal

About the 8280-419

The 8280-419 unit is part of the 723PLUS Digital Speed Control for Single Engine Marine Propulsion Applications from Woodward Governor. Two versions of this control are available; model 8280-419 is compatible with medium- and high-speed diesel reciprocating engines. For a low-speed compatible model, see the 8280-418. Both versions of this 723PLUS control are low-voltage models with a power supply rated for 18-40 Vdc.

The 8280-419 control can be used in variable-speed marine propulsion service applications to control both the speed and load of the diesel engines. This control can be used in applications with flexible couplings since the two-speed sensor inputs can be used for magnetic pickups (MPUs) or proximity switches.

Several communication ports on this unit support various options for interfacing with the control for configuration, monitoring, and troubleshooting. These options include Watch Window; the Woodward Hand Held Programmer; 723PLUS Marine SEP Control View software; and RS-232, RS-422, and RS-485 communications. More information on these 723PLUS Digital Speed Control accessories, including the part numbers for each communication, can be found in Woodward 723PLUS Product Manual 02880.

Like other 723PLUS controls, the 8280-419 is in a metal enclosure. It is rated for a -40 to +70 °C (-40 to +158 °F) temperature range during operations but can withstand a -55 to +105 °C (-67 to +221 °F) range during storage. This control is susceptible to electromagnetic interference and should be installed in a location that protects it from such conditions. Manual 02880 has additional safety information and should be reviewed before installing this unit.

Frequently Asked Questions about 8280-419

What are the controls needed to properly operate the 8280-419 model?

There are several controls required to run the 8280-419 model with the single marine engine application without any issues occurring. One of the controls is the power supply needed. The power supply required for this model is 40 watts of power, with a potential in-rush current of 7A. The input voltage range that can be used with the 8280-419 unit is 18 to 40 VDC. Another feature is that discrete input voltages can be used and often provide on/off command signals to raise and lower the speed of the electronic control.

What is the specific system type that the 8280-419 model will be used in?

The system that the 8280-419 model is used in is a single-engine marine propulsion system that is used to control single propellor, single-engine propulsion systems. It should be noted that the single propellor can either be fixed or variable pitched. Protection for the propulsion system will be provided with special torsional detection, filtering across flexible coupling, and fuel limiters.

Reviews For 8280-419

Internal Review
(4.0)

Due to limited market availability and high demand, model 8280-419 will be difficult to supply. Due to the limited availability of this model, it is likely that instead of purchasing this model, another model within the 723PLUS series, but caution should be taken when doing so as purchasing a model that does not work with Single Marine Engine Propulsion Applications can affect how the prime mover will run. - AX Control Tech
