EasyGen-3200-1-P1

About the EasyGen-3200-1-P1

This generator set controller is an easYgen-3000 series model from Woodward. easYgen-3200-1-P1 is designed for versatility and can be configured for use in a range of applications. AMF, peak shaving, cogeneration, and standby are a few examples. Up to 32 gensets connected with automatic sequencing can be controlled by this unit. easYgen model 3200-1-P1 meets IP20 standards.

The 3200-1-P1 has a multi-level password-protected operator interface built-in into the unit’s plastic housing. This HMI has a back-lit, color LCD, and protected soft keys. This model is designed for front panel flush mounting. If cabinet back mounting is required, a 3100/3400 model should be used instead.

This easYgen model can be configured via the built-in operator interface or PC (ToolKit software and serial connection). An event recorder with real-time clock and battery backup maintains up to 300 entries (FIFO). easYgen model 3200-1-P1 has start/stop logic for both diesel and gas engines.

As a 1-P1 version, this unit has 1A CT inputs and is without PID controllers. I/Os of the P1 models (analog and discrete) differ from those on the Package 2 models, details of which may be found in Woodward easYgen 3000 production specification sheet 37258P. Operation information for easYgen-3200-1-P1 is in Woodward Manual 37532E.
