8290-147

Name: 8290-147
Brand: Woodward
SKU: 8290147WO
Price: 1789 USD
Availability: LimitedAvailability
Rating: 5 (1 reviews)

5.00 (1)
Click a star to rate this product

5.00 (1)
Click a star to rate this product

Woodward Isochronous Speed Control part 8290-147 is used with the 4024 actuator model which needs a larger terminal lever at .500-36 serrations and 42° rotations. Make sure that before installing an actuator with this model, it can be used within the work output of the attached actuator.

Request a Quote Request Repair

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a 8290-147 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: 8290-147
SKU: 8290147WO

Manufacturer: Woodward
Series: EPG Electrically Powered Governor

Description
Repairs
Warranty
Manuals

8290-147 Technical Specifications

Actuator Rotation for 4024 Model	42°
Model Type	Isochronous Speed Control
Preferred Actuator Shaft Movement	28°
Series	EPG, Electrically Powered Governor
System Battery Voltage	24-Volt
Wiring Length from Control to Actuator	12 ft. (12 AWG) and 4 ft. (14 AWG)

About the 8290-147

The speed control device 8290-147 is a Woodward product that is part of the Electrically Powered Governor series. This model is designed with screw clamp terminals and can be installed near the battery and actuator it will be used with. The device is made to be used on prime movers with low mass and low friction. It does not need a mechanical drive or hydraulic oil supply. Model 8290-147 is an isochronous device, and operates with 42-degree rotations. It should be installed with 12 AWG and 14 AWG wiring, with length requirements being followed. The 12 AWG wire has a maximum length of 12 feet, and the 14 AWG wire has a 4 feet length maximum.

Specifications for model 8290-147 include;

A 24-volt system battery voltage.
Weight of fewer than two pounds.
EU Directive Compliant.
Optional use with load-sharing accessories and a ramp generator.
Temperature range of -40 to 93 degrees Celsius.
Start fuel limit.
Use of switch-select dual dynamics.

Speed control device model 8290-147 has been discontinued by Woodward and is no longer available through the original manufacturer. However, it can be found through sources like AX Control. AX Control will buy, sell, or repair these products. Any purchases are also given a three-year warranty.

Reviews For 8290-147

Internal Review

(5.0)

The 8290-147 model is an isochronous speed control model that is strictly used with a 4024 actuator, when these models are being used together, please make sure that the wire lengths are correct between the length from the battery to the control and from the control to the actuator. - AX Control Technician

Repair Services For 8290-147

Type	Lead Time	Price	Action
Repair Service	1-2 weeks	$1789

Our highly skilled technicians can repair your 8290-147. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

48-72hr Rush Repair
Detailed Repair Reports
AX Control Certificate of Warranty
