Woodward 8290-191 from the Electrically Powered Governor Series. This model is a droop speed controller that operates on a system battery voltage of 24 volts. The 8290-191 model will operate on a power consumption of 95 W, with a battery charger of at least 5 A.
Request a Quote Request Repair
Request a Quote Request Repair

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a 8290-191 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8290-191
  • SKU: 8290191WO
  • Manufacturer: Woodward
  • Series: EPG Electrically Powered Governor

8290-191 Technical Specifications

Actuator Models Used 1712/1724 and 512/524
Ambient Temperature Range –40 to +167 °F
Manufacturer Woodward INC in Fort Collins, CO
Model Type Speed Control, Droop
Series Electrically Powered Governor, EPG
System Battery Voltage 24 Volts
VDC Range min. 20 VDC to max. 32 VDC

About the 8290-191

Model 8290-191 is a Woodward droop speed control device. This product is only compatible with certain types of actuators and comes from the Electrically Powered Governor series. Actuators that can operate with this device include 1712, 1724, 512, and 524.

Operation details for speed control model 8290-191 include;

  • A system battery voltage of 24.
  • An ambient temperature range from -40 to 167 degrees Fahrenheit.
  • VDC range of 20 VDC to 32 VDC.
  • Maximum power consumption of 95 watts.
  • Minimum battery charger capability of 5A.
  • Available workload of 1.7 pounds.
  • A start fuel limit.

Speed control model 8290-191 is compliant with EU directives and can work on prime movers with no mechanical drive or hydraulic oil supply. To create an entire EPG system for a prime mover, a speed control device, magnetic pickup, and actuator are needed. When mounting the speed control, it can be placed between the battery and the actuator for optimal use. This product can also accept load-sharing accessories when operating and uses switch-selected dual dynamics.

Reviews For 8290-191

Internal Review
(4.0)

The Woodward model 8290-191 needs specific wiring lengths to connect to the battery and the control, if the correct wiring is not used potential errors could occur. - AX Control Tech Team

Repair Services For 8290-191

Type Lead Time Price Action
Repair Service 1-2 weeks $1345

Our highly skilled technicians can repair your 8290-191. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:
