8237-1601

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (4)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (4)
  • Click a star to rate this product
Woodward's 8237-1601 allows failure detection in Overspeed system components to be repaired or replaced while the monitored system continues to operate online.
Request a Quote Request Repair
Request a Quote Request Repair

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a 8237-1601 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8237-1601
  • SKU: 82371601WO
  • Manufacturer: Woodward
  • Series: ProTech-GII Overspeed Protection

8237-1601 Technical Specifications

Dimensions 330mm x 445mm x 159mm
Enclosure Type IP56 in an IP56 Enclosure/Cabinet
Features Reverse Polarity Protection
High Input Voltage Nominal 115 Vac / 240 Vac / 125 Vdc
Keypad/Display (3) 107mm Displays
Low Input Voltage Nominal 24 Vdc
Operating Temperature –4 to +140 °F
Slot Type 1 Serial Com Port per Module
Storage Temperature –4 to +158 °F
Weight 23 lbs before shipping

About the 8237-1601

A panel mounts over acceleration detection device from Woodward is model 8237-1601. It’s part of the Protech-GII series and works with any size turbine. It can be used on any turbine powered by steam, gas, or water, and will safely shut them down if they begin to accelerate too quickly. Each of the three independent relays has individual alarms. Model 8237-1601 uses two out of three voted architecture and two dual relay outputs. The sulfur-resistant conformal coating allows for this safety device to be used in class 3C2 environments. It has the international standard of IEC 721-3-3 1994.

Model 8237-1601 uses three separate modules, allowing for one to be worked on while the others are functioning. It can be configured to run over speed tests using an internal generator, and the results of these will be logged. The backplane design makes repairs and replacements easy and straightforward. In addition to acceleration detection, this safety device also uses open-wire MPU detection. This product is equipped with Modbus communication, in addition to high voltage and low voltage power inputs.

Reviews For 8237-1601

Internal Review
(5.0)

Depending on the ProTech-GII model purchased, the internal modules will accept either two high voltage input power sources or one HV input power source and one low voltage input power source. - AX Control Tech Team

Repair Services For 8237-1601

Type Lead Time Price Action
Repair Service 1-2 weeks $5655

Our highly skilled technicians can repair your 8237-1601. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
