EA7-S6C-R

About the EA7-S6C-R

The EA7-S6C-R AutomationDirect C-more Touch Panel 6-inch Display can be used to interface with a programmable logic controller (PLC) and to control processes through use of the touch screen. The EA7-S6C-R supports a 32-Bit RISC (333 MHz) microprocessor. The EA7-S6C-R supports two USB ports: USB A (dedicated to optional devices) and USB port B (dedicated to programming and downloading).

The viewing area is 4.54" (W) x 3.4" (H)  [1152 mm x 86.4 mm]. The contrast is adjustable from the configuration menu and the display supports a 256 color scale.

The EA7-S6C-R AutomationDirect C-more Touch Panel 6-inch Display features a super-twisted nematic (STN), 320 x 240 Quarter Video Graphics Array (QVGA) display.The EA7-S6C-R is wrapped in a NEMA 4/4X enclosure for reliability and durability.

Available system memory is 32 MB SDRAM. The EA7-S6C-R supports up to 9999 screens with programming software version 2.40 and later, depending on project memory usage.

Serial communications is available through the serial port PLC RS-232C/422/485 15-Pin D-sub (female) connector. The input voltage range is 24 VDC (20.4–28.8 VDC operating range).

If required for the hardware configuration, the recommended DC supply fuse is type 2.5 A time delay. The operating temperature is 0 to 50℃. The humidity is 5-85% RH, non condensing.

The dimensions of the EA7-S6C-R AutomationDirect C-more Touch Panel 6-inch Display are  6.140" x 8.047" x 1.697" [156.0 mm x 204.4 mm x 43.1 mm]. The weight is  1.39 lb. [630 g].
