EA-MG-SP1

About the EA-MG-SP1

EA-MG-SP1 is an optional serial port with a DC power adapter for C-more 3 inch micro panels that are manufactured by Automation Direct. The serial port is a D-Sub 15-pin RS-232 / RS-422 / 485 connector. While this is an optional addition to the micro panel, it is required when using RS422, RS485 or third party PLCs. The dimensions are 97.1 mm x 83.4mm x 47.4 mm, and the weight of this unit is 125 grams. The electrical connector type is a 3-pin screw type terminal block. The recommended fuse is a Type AGC fast acting glass fuse (750 mA, 250 VAC, ADC p/n AGC-75). With 12 VDC power applied, the maximum inrush current is 5 A at 500 µs. With 24 VDC power applied, the maximum inrush current is 10 A at 500 µs. The maximum power is 2.9 watts. The power consumption at 24 VDC is 100 mA. The input voltage is 12-24 VDC, and the input voltage range is 10.8-26.4 VDC. The serial PLC interface port is a female 15-pin D-sub connector. The interface standard is RS232 and R485/422.
