D4-16TD1

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
Automation Direct Facts Engineering Koyo PLC Direct D4-16TD1 DC Output Module DL405

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a D4-16TD1 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: D4-16TD1
  • SKU: D416TD1AD
  • Manufacturer: Automation Direct
  • Series: DirectLogic 405

About the D4-16TD1

The Automation Direct Facts Engineering Koyo D4-16TD1 is a DC output module. Developed for the DirectLogic 405 series, this 16 channel output is designed to install in DL405 programmable logic controllers. Aside from the PLC, this module supports interfacing with a variety of peripheral devices as well. All sixteen outputs are current sinking, with two internally connected commons serving as the terminating points for the channels.

Monitoring voltage and current levels in the module prevents unnecessary overloading or damages. D4-16TD1 requires an operating voltage between 4.5 and 26.4 VDC for proper function. The peak sustainable voltage the module can support registers at 40 VDC. An NPN open collector output type is produced by the module. Each channel of the device can sustain maximum resistive current of 0.5 A per point. Both commons, though, supports a maximum resistive current of 3 A per common. A required 5V base power of (maximum) 200 mA is needed to sustain the module.

Follow all installation and storage parameters to prevent any unnecessary damage to the module. D4-16TD1 requires a climate controlled environment to prevent any temperature damage. When operating, ambient temperatures should fall no lower than 0℃, or 32℉, and raise no higher than 60℃, or 140℉. Even when not in use, storage temperatures can affect the quality of the module. Storage temperatures can safely range from -20℃ to 70℃, or -4℉ to 158℉. All wiring and installation guides are available in the series manual and the device datasheet. Automation Direct provided original technical support for the module.

AX Control is happy to help with your D4-16TD1 needs. Please contact our office by phone or email to receive current pricing on all parts and repairs.
