F4-CP128-T

About the F4-CP128-T

The F4-CP128-T CoProcessor Module contains 3 ports. Port 1 is a RS-232C/422/485, 57.6 Kbaud maximum, Port 2 is a RS-232C 9600 baud maximum, and Port 3 is a RS-232C, 9600 baud maximum. The module contains 9 pin D-sub connectors for port 1 and port 2. Port 3 uses a RJ12 connector located on the bottom of the module.

The F4-CP128-T CoProcessor Module is designed to interface with barcode readers, board level controllers, intelligent sensors, and almost any device with a RS-232/422/485 port. The power consumption is 350 mA at 5VDC. The operating environment is 0ºC–60ºC (32ºF–140ºF), 5% to 95% humidity (non-condensing). You can have a maximum of eight per DL405 and the F4-CP128-T CoProcessor Module can be installed in any I/O slot.

The  F4-CP128-T CoProcessor Module is designed to interface with the DL405 programmable device. To enable full serial port utilization, you can program the module from port 1 or port 2 without the need to switch cables.

The ABM Commander for Windows software package comes packaged with the module. It comes on a CD. The software package enables you to perform on-line full-screen program editing.

A maximum of 128K bytes of non-volatile memory enables you to store multiple program storage and execution, DL405 register expansion, and retentive data storage and retrieval.
