H4-ERM-F

Name: H4-ERM-F
Brand: Automation Direct
SKU: H4ERMFAD
Price: 240 USD
Availability: InStock
Rating: 4.6 (5 reviews)

4.60 (5)
Click a star to rate this product

4.60 (5)
Click a star to rate this product

Ethernet module H4-ERM-F has 10BaseT Ethernet communications with a 10 Mbps data transfer rate manufactured by Automation Direct for the DirectLogic 405 family. This module only has one ST-style fiber optic port.

Request a Quote Request Repair

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a H4-ERM-F to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: H4-ERM-F
SKU: H4ERMFAD

Manufacturer: Automation Direct
Series: DirectLogic 405

Description
Repairs
Warranty
Manuals

H4-ERM-F Technical Specifications

Model Number	H4-ERM-F
Series	DL405, DirectLogic 405
Manufacturer	Automation Direct; Host Automation Products, L.L.C
Product Type	Ethernet Remote I/O Master Module
5V Current Consumed Value	450
Used With	DL405 and DL205
Ethernet Protocols	TCP/IP, IPX
Power Consumption	450 mA @ 5 VDC

About the H4-ERM-F

The H4-ERM-F module is a fiber optic ethernet remote I/O master module that was created by AutomationDirect for the DirectLogic 405 series. The H4-ERM-F module has two closely related products, the H4-ERM module, and the H4-ERM-100 module. All three of these modules are closely related yet have some differences in the specifications.

All of the H4-ERM modules are compatible with DirectLogic 205, DirectLogic 405, Do-more PLC systems, and WinPLC systems. The H4-ERM module connects with the ethernet remote slave modules using the 10BaseFL fiber optic ethernet link cable. Each H4-ERM module can have a maximum of sixteen slave modules connected when using the DirectLOGIC 205, DirectLOGIC 405, and the Do-more PLC systems.

The H4-ERM-F module uses 10BaseFL ethernet communication methods, has an ST-style fiber optic ethernet port, and uses TCP/IP and IPX ethernet protocols. The link distance for the H4-ERM-F module is very long at 2,000 meters or 6,560 feet. The power consumption rating of the H4-ERM-F module is 450 mA at 5 VDC.

As mentioned above, the H4-ERM-F module has an ST-style connector that will use a quick-release coupling requiring it to be turned a quarter for engaging or disengaging functions. The ST-style connectors on the module can connect another H4-ERM-F model or a fiber optic repeater or hub. When the connectors are being used with fiber optic cables, the module will accept multimode fiber optic cables 62.5 or 125. The cabling used is best to permit communications and immunity to noise.

Frequently Asked Questions about H4-ERM-F

What is the H4-ERM-F?

The H4-ERM-F is an Ethernet Remote Input Output Master Module. The communication type on this unit is 10BaseFL Ethernet communications. The appropriate data transfer rate on the module is 10 Mbps. It has an ST-style fiber optic Ethernet port with TCP/IP and IPX Ethernet protocols.

What are the differences between the Ethernet Remote Master modules?

The main difference between the three Ethernet Remote Master (ERM) modules is the communication types. The H4-ERM-F module has 10BaseFL Ethernet communications, with the H4-ERM having 10BaseT Ethernet communications, and the H4-ERM100 having 10/100BaseT Ethernet communications. The base ERM module has a data transfer rate of 10 Mbps, which the H4-ERM-F also does. Another difference between the three units is the power consumption; the H4-ERM-F module has a higher power consumption of 450 mA, with the H4-ERM at 320 mA and the H4-ERM100 at 300 mA.
