About the IS5100-C11
The image acquisition of the In-Sight IS5100-C11 Vision System is 24 bit color at 60 full frames per second.
The operating temperature of the IS5100-C11 is 0°C to 45°C (32°F to 113°F). The operating humidity is 95%, non-condensing (operating and storage). The Ingress Protection rating is IP67 (with appropriate lens cover installed). The vibration rating (shipping and storage) is 10 G from 10-510 Hz with 150 gram lens per IEC 68-2-6. The shock rating (shipping and storage) is 80 G shock with 150 gram lens attached per IEC 68-2-27.
To install the In-Sight IS5100-C11 Vision System, you must install the lens, connect the Ethernet cable, connect the breakout cable, install the In-Sight Explorer software on a networked laptop, or other device, and log on to the Vision System.
The IS5100-C11 contains 32MB non-volatile flash memory and unlimited storage through a remote network device. The image processing is 64 MB. The resolution is 640x480. The sensor is ⅓-inch CCD. The weight is 350 g (12.3 oz.) with the lens cover installed and without the lens. The IS5100-C11 is surrounded in a die-cast aluminum housing.
The minimum firmware requirement for the IS5100-C11 is In-Sight version 3.4.0.
With the lens installed, the dimensions are 83.3mm (3.28in) x 123.2mm (4.85in) x 61.4mm (2.42in). Without the lens cover installed, the dimensions are 43.5mm (1.71in) x 123.2mm (4.85in) x 61.4mm (2.42in) including the thread guard.
Before you install the IS5100-C11, consider that the device must be supplied with a 24VDC output rated for at least 600 mA continuous and a maximum short circuit current rating of less than 8A and a maximum power rating of less than 100VA and marked Class 2 or Limited Power Source (LPS). The power source must be UL or NRTL listed.
