IS5110-01

About the IS5110-01

The image bit depth of the In-Sight IS5110-01 Vision System is 256 grey levels (8 bits/pixel) at 60 full frames per second. The minimum firmware requirement for the IS5110-01 is In-Sight version 4.4.3.

To install the In-Sight IS5110-01 Vision System, you must install the lens, connect the Ethernet cable, connect the breakout cable, install the In-Sight Explorer software on a networked laptop, or other device, and log on to the Vision System.

The IS5110-01 contains 128MB non-volatile flash memory and unlimited storage through a remote network device. The image processing memory is 256 MB. The resolution is 640x480. The sensor type is ⅓-inch CCD. The weight is 350 g (12.3 oz.) with the lens cover installed and without the lens. The IS5110-01 is surrounded in a die-cast aluminum housing.

The operating temperature of the IS5110-01 is 0°C to 45°C (32°F to 113°F). The operating  humidity is 95%, non-condensing (operating and storage). The Ingress Protection rating is IP67 (with appropriate lens cover installed). The vibration rating (shipping and storage) is 10 G from 10-500 Hz with 150 gram lens per IEC 68-2-6. The shock rating (shipping and storage) is 80 G shock with 150 gram lens attached per IEC 68-2-27.

With the lens installed, the dimensions are 83.4mm (3.28in) x 124.2mm (4.89in) x 61.4mm (2.42in). Without the lens cover installed, the dimensions are 43.5mm (1.71in) x 124.2mm (4.85in) x 61.4mm (2.42in) including the thread guard.

efore you install the IS5100C, consider that the device power consumption is 24VDC ±10%, 500mA maximum.
