About the IS5411-10
The image bit depth of the In-Sight IS5411-10 Vision System is 256 grey levels (8 bits/pixel) at 17 full frames per second.
The breakout cable is used with the device for many signals, VDC power supply, all the output signals (trigger and high-speed). The breakout cable is an option you can purchase. The device has a dedicated connector that the cable connects in to. The cable has 8 wires that provide the connections.
One wire enables the electrical connection (24 VDC)
One gives the positive trigger signal
One gives the zero (0) high-speed output signal
One gives the one (1) high-speed output signal
One give the receiving serial signal
One gives the transmit serial signal.
One is the ground.
You’ll need to plan carefully for the installation of the device. These are some of the issues:
-
Is the environment safe for the device
-
Is there a network connection near by
-
Is there a means to mount the device for operation
-
Is there a 24VDC plus or minus 10% power at 500mA electrical power source? This is the maximum power value.
The In-Sight IS5411-10 Vision System features Power, Network Status, and Network Traffic indicator LEDs. It also contains two user-configurable indicator LEDs.
Firmware updates are provided for the IS5411-10 is In-Sight version 4.4.3. It is good practice to keep the device up to date with the latest firmware that is available. You can do this by checking the website and verifying that the latest is installed on your device. If you find a newer version you can download it and install it. Before you do, make sure the software is designed for the device. Also, check any notes that come with the software.
