IS8402M-363-50, Cognex Assembly Line Camera

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a IS8402M-363-50 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: IS8402M-363-50
  • SKU: IS8402M36350CV
  • Manufacturer: Cognex Vision
  • Series: In-Sight 8000

About the IS8402M-363-50

IS8402M-363-50

Cognex In-Sight 8000 assembly line camera series. Model ID IS8402M-363-50. Case constructed from zinc-based alloy, painted yellow and black. Includes M3 threaded mounting holes, four of them are at the base, and they require a C mount. (On the accessory mounting block there are M6 mounting holes). In-Sight 8402 products include 5.2.0 firmware.

Standard product measurements are 31 mm by 31.2 mm by 75.1 mm (1.22 in by 1.23 in by 2.96 in), weighs 132.2 grams (4.66 ounces). With the mounting block accessory, the dimensions become 39 mm by 31.2 mm by 75.1 mm (1.54 in by 1.23 in by 2.96 in), and the weight is increased to 163.2 grams (5.76 ounces). Case temperature ranges from 0 to 50 degrees celsius (32 to 122 degree fahrenheit), and storage temperature for the unit ranges from -20 to 80 degrees celsius (-4 to 176 degrees fahrenheit).

Model designed with a 1600 x 1200 pixel resolution, at 53 frames per second, completely monochrome. Equipped with a 1/1.8 inch CMOS sensor, and global shutter. The model’s 1 entry port is for a Gigabit Ethernet bit, with 2 outgoing fast transfer ports, 1/2 D barcode reader. Image monitors and filters, geometric program and pattern recognition, histogram data are also included, and the model is capable of both formatting and string parsing, and has a built-in caliper assessing tool that calibrates products nonlinearly. The IS8402M-363-50 is installed with the essential tool programs EasyBuilder, InspectEdge, JavaScript, PatMax, Spreadsheet.

Repair Services For IS8402M-363-50

Type Lead Time Price Action
Repair Service 1-2 weeks $1974

Our highly skilled technicians can repair your IS8402M-363-50. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
