ISM1050-00

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
Vision System ISM1050-00 is one of the basic In-Sight Micro Modes. This model does not have PatMax, color, or ID tool features and only has a standard resolution. The speed rating for this model is virtually identical to that of the ISM1020 model.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a ISM1050-00 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: ISM1050-00
  • SKU: ISM105000CV
  • Manufacturer: Cognex Vision
  • Series: In-Sight Micro Series Vision System

ISM1050-00 Technical Specifications

Bit Depth 256 Grey Levels (8 bits/pixel)
Compliance Types FCC, KCC, RoHS, CE, and TÃœV SÃœD NRTL
Finish Painted
Frames Per Second 60
Lens Type C-Mount and CS-Mount, with 5mm extension included
Manufacturer Cognex Corporation out of Natick MA
Network Communication 1 Ethernet Port, 10/100 Base T with Auto MDI/MDIX
Sensor Properties 5.92 mm diagonal, 7.4 x 7.4 µm sq. pixels
Status LEDs Quantity Three
User Interface(s) Spreadsheet and EasyBuilder

About the ISM1050-00

The ISM1050-00 model is another one of the basic models produced within the In-Sight Micro (ISM) Series. While this model is one of the most basic models it can still perform a variety of functions that makes this vision system a great purchase. Two features that typically go hand-in-hand with each other are this model's ability to perform single-point inspections while also being able to be set up in a factory-wide network. This model is also small and compact with its dimensions being under three inches in depth, width, and height no matter if being used with or without a mounting block.

Models produced by Cognex are often purchased for their ability to be used in a variety of flexible displays. There are eight features associated with the flexible display and VisionView Applications software, one of which is fast image updates. The fast image updates feature can issue the most up-to-date inspection images so the view can be processed in real-time. The remaining features of the VisionView Software can be found in the In-Sight Vision System Product Guide on page twelve.

Three cables are associated with the ISM1050-00 model which are Ethernet, I/O module, and breakout cables. There are several lengths used in relation to all of these cables, the Ethernet cable has six lengths ranging from 0.6 meters to 30 meters. In relation to the Ethernet cable, there are also two right angle keys, one being a one hundred and thirty-five-degree key and a forty-five-degree key, each of the keys are described as M12 connectors. Please note that no right-angle keys are associated with the 0.6-meter cable.

Frequently Asked Questions about ISM1050-00

What are some general specifications for the ISM1050-00 Cognex In-Sight Micro Vision System that differentiates it from other Cognex Vision systems?
The ISM1050-00 vision system contains the In-Sight version 4.4.3 in regard to the minimum filmware requirement for use. Some systems, like the 1402 Cognex systems, use a minimum filmware requirement version 4.6.0. All of the Cognex In-Sight vision systems, including the ISM1050-00, contain 128 MB of flash memory that is non-volatile. They also have an unlimited storage capacity by the use of a remote network. Additionally the ISM1050-00, and other Cognex vision system have an image processing memory of 256 MB SDRAM.
What type of sensor does the ISM1050-00 Cognex In-Sight Micro Vision System have compared to other models of the Cognex products, and what are the characteristics of that sensor?
The ISM1050-00 Cognex In-Sight Micro Vision System has a 1/3 inch CCD sensor. The Cognex 1020, 1100, 1110, 1100C, 1410, 1400C, and the 1400 vision systems have this specific type of sensory as well. The sensor properties are a 5.92mm diagonal, 7.4 micrometer by 7.4 micrometer sq. pixel dimension. The maximum resolution for these pixels is 640 by 480. The electronic shutter speed for the ISM1050-00 Cognex In-Sight Micro Vision System is 16 microseconds to 10000 ms.

Reviews For ISM1050-00

Internal Review
(5.0)

If looking for a basic In-Sight Micro model that has a low-speed rating but also has a standard resolution and both the Spreadsheet and EasyBuilder user interfaces then the ISM1050-00 model is the perfect model for you. - AX Control Tech Team

Repair Services For ISM1050-00

Type Lead Time Price Action
Repair Service 1-2 weeks $576

Our highly skilled technicians can repair your ISM1050-00. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
