ISM1100-00

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.00 (1)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.00 (1)
  • Click a star to rate this product
Micro Vision System ISM1100-00 is one of the models potentially equipped with a PatMax tool feature but does not have a color tool set. This unit has a standard resolution of 640 x 480 pixels.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a ISM1100-00 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: ISM1100-00
  • SKU: ISM110000CV
  • Manufacturer: Cognex Vision
  • Series: In-Sight Micro Series Vision System

ISM1100-00 Technical Specifications

Bit Depth 256 Grey Levels (8 bits/pixel)
Current Per Class 2 PoE Requirements
Discrete Outputs High-Speed PNP/NPN
Mounting Four M3 Threaded Mounting Holes
Protection Type IP51 w/ Cables and Lens Attached
Storage Vibration 10 G
Trigger One Opto-Isolated Acquisition Trigger

About the ISM1100-00

Product ISM1100-00 is a compact, stand-alone, and network-ready Vision System that can be used in factory settings on a large factory-wide network system. The model can help with the guidance of robots, measurement, identification, and inspection applications. While operating the model if you wish to change the configuration it can be done so over a network using the inherent user interfaces.

According to the In-Sight Micro Vision System Product Guide, one of the things that the ISM1100-00 model is best known for is the resolution. The resolution associated with this model is a standard resolution of around sixty hundred and forty to four hundred and eighty pixels. The resolution allows for the unit to handle some of the highest-speed manufacturing lines with the most minute vision system footprint.

One important note that should be made regarding this vision system is that the amount of image sensor rows can be configured to the users liking if the rows are decreased then the frames per second will be increased.

Due to similarities between the In-Sight Micro and In-Sight Track and Trace models the ISM1100-00 model can be connected to one of the Track and Trace models. When used together the two vision systems can create a total data verification and identification solution for serialized labels for medical device packaging. Some of the features including are reading 1D and 2D barcodes including GS1-128, GS1 DataBar,  Pharmacode, and Data Matrix. For more ways in which the In-Sight Micro and In-Sight Track and Trace models will be used together refer to the aforementioned product guide.

Frequently Asked Questions about ISM1100-00

What are the characteristics of the Ethernet port on the ISM1100-00 Cognex Vision System?
The ISM1100-00 has a single Ethernet port that supports factory default DHCP link-local and static IP address configurations. The single Ethernet port has a 10/100 baseT with an auto MDI/MDIX.  Over the Ethernet device, the vision series has a class 2 power specification of type A and B.
What are the voltage and current characteristics of a ISM1100-00 Cognex Vision System
The ISM1100-00 Cognex Vision System has a power consumption listed as a maximum of 6.49 W per class 2 PoE (which is the power specification for the system). The current is defined as per the class 2 PoE requirements as well. This ISM1100-00 Cognex Vision System has a 48 VDC nominal voltage that is applied to the system powered from another voltage by the class 2 PoE injector.
What differentiates the Cognex In-Sight ISM1100-00 Vision System from other Cognex systems providing stand-alone, network-ready, compact inspection, identification, and guidance for robots across factory floor conditions?
The Cognex In-Sight ISM1100-00 Vision System is unique from other vision systems that are 1402 models or higher because it accepts a minimum firmware requirement of version 4.4.3. It also has a sensor of type 1/3 inch CCD.

Reviews For ISM1100-00

Internal Review
(5.0)

One upside of owning the ISM1100-00 model is that it has the ability to connect with other Cognex models. When it connects with the In-Sight Track and Trace models it can verify the correct ID code content. - AX Control Tech Team

Repair Services For ISM1100-00

Type Lead Time Price Action
Repair Service 1-2 weeks $598

Our highly skilled technicians can repair your ISM1100-00. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
