ISM1100-C00

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
Model number ISM1100-C00 is one of the many In-Sight Micro Vision Systems but is only one of a select few color vision systems designed by Cognex. This unit does have the potential to support a PatMax feature thanks to its extended toolset feature.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a ISM1100-C00 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: ISM1100-C00
  • SKU: ISM1100C00CV
  • Manufacturer: Cognex Vision
  • Series: In-Sight Micro Series Vision System

ISM1100-C00 Technical Specifications

Acquisition Rate 58 FPS
Color Model Yes, according to Cognex In-Sight Micro Vision System Data Sheet
Essential Tool Set Features Image Filters, Pattern Matching, Standard Calibration, Histogram, Etc.
Finish Painted
Housing Material Die-Case Zinc
Protection Type IP51
Regulatory Compliances KCC, CE, RoHS, FCC, and TÃœV SÃœD NRTL
User Interface(s) Spreadsheet and EasyBuilder
Weight w/o Mounting Block Approx. 4.3 oz

About the ISM1100-C00

In-Sight Micro Series Vision System ISM1100-C00 was one of the first color vision systems to be produced when Cognex produced the systems back in 2010. Since then eleven more color vision systems have been developed and joined this model. One of the models associated with this unit is the ISM1100-C10 which does have supported PatMax features thanks to the extended tool set. All of the features that come with the associated tool sets are listed in the attached Cognex In-Sight Micro Vision Data Sheet; if you desire more information on the advantages and the ways in which the features can best be utilized refer to pages eight and nine in the In-Sight Micro Series Vision System 2010 Product Guide.

There are two user interfaces that are used with the ISM1100-C00 model, one of them being the EasyBuilder Interface; the EasyBuilder Interface will be used in conjunction with the In-Sight Explorer Software. The two software interfaces being used together make setting up the vision application even easier as it will go step-by-step. The EasyBuilder software is best suited for beginners who have never set up a vision application before but does not require any type of programming experience. The In-Sight Explorer Software is often used for more advanced vision system users and allows for the flexibility of the available spreadsheet interface to program solutions for some of the most difficult applications.

While the ISM1100-C00 model is a stand-alone and network-ready vision system it does require some cabling to allow for different connections; the standard cables used with this vision system are either breakout, I/O module, or Ethernet cables. All information on cables will be found in the In-Sight Micro Series Vision System Installation Manual.

Frequently Asked Questions about ISM1100-C00

How does the bit depth compare for the different model specification of the Cognex In-Sight Micro Series Vision Systems?
The bit depth for a Cognex vision system will vary based on the different specification of the Cognex Micro Series Vision System in question. For example, if the vision system has a C following the four digit specification code then this is a color indicator, meaning the vision system is equipped with a 24 bit color bit depth. Cognex vision systems 1100C, 1400C, and 1403 have this color feature. All other vision systems (1020/1050, 1100/1110, 1400/1410, 1402/1412,1403/1413, and 1500 vision systems) have a bit depth feature of 256 grey levels at 8 bits per pixel. The maximum pixel resolution for the 1020/1150, 1100/1110, 1100C, 1400/1410, and the 1400C micro vision system specification is 640 x 480. This dimension increases to a pixel resolution of 1280 x 1024 for a1402 or 1412 Cognex Vision System. The 1403/1413 or 1403C vision systems have a pixel resolution of 1600 x 1200. The 1500 is listed as either having a pixel resolution of 640 x 480 or 800 x 600. The default pixel resolution for a 1500 vision system is the first pixel range (640 x 480). However with the In-Sight Explorer software this resolution can be updated to the second pixel specification (800 x 600).

Reviews For ISM1100-C00

Internal Review
(4.0)

One of the main downsides of purchasing this model is that it is one of the first color vision systems produced by Cognex and does not have some of the features that other models that have been produced do. - AX Control Tech Team

Repair Services For ISM1100-C00

Type Lead Time Price Action
Repair Service 1-2 weeks $577

Our highly skilled technicians can repair your ISM1100-C00. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
