ISM1402-01

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.00 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.00 (2)
  • Click a star to rate this product
The ISM1402-01 model is part of the Cognex series of devices, this specific unit is an In-Sight Micro Vision System that is a compact and a stand-alone model. This model can be used with Ethernet, I/O modules, and breakout cables.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a ISM1402-01 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: ISM1402-01
  • SKU: ISM140201CV
  • Manufacturer: Cognex Vision
  • Series: In-Sight Micro Series Vision System

ISM1402-01 Technical Specifications

Bit Depth 256 Grey Levels
Finish Painted
Job/Program Memory Non-Volatile Flash Memory, 128 MB
Manufacturer Cognex Corporation, Natick MA
Mounting Four M3 Threaded Mounting Holes
Sensor Properties 8.7 mm diagonal, 5.3 x 5.3 µm sq. pixels
Serial Communication None
Shock 80 G w/ 50 Gram or Lighter Lens
Trigger 1 Opto-Isolated Acquisition Trigger Input
Weight w/o Mounting Block 4.27 oz (121 g)

About the ISM1402-01

Produced by Cognex Vision the ISM1402-01 model is just one of the many In-Sight Micro Vision Systems. Vision systems of this variety are predominantly used in applications where something must be identified including but not limited to alphanumeric characters, barcodes, or items that need to be identified by their shape. One advantage of using this model is the small packaging where the model can be used with or without a mounting block, when the model is being used without a mounting block the dimensions of this unit are 1.18” (30 mm) by 1.18” (30 mm) by 2.36” (60 mm).

Two user interfaces can be used with this unit, the two interfaces are Spreadsheet and EasyBuilder, when being used with the EasyBuilder interface the ISM1402-01 model is used for building a factory-wide network of vision systems or single-point inspection tasks. In terms of the resolution of this model, it is not quite high resolution but not quite standard either, the maximum number of pixels used with this model is 1280 by 1024.

There are a variety of inputs and outputs that can be connected to the ISM1402-01 model, it must be noted that the cable connectors are specifically designed and keyed to fit the connectors of this device; under no circumstances should the connections be forced or else damage could possibly occur. Another specification regarding this model is that all adjustments and wiring regarding the inputs and outputs must be executed when no power is available on the system.

Frequently Asked Questions about ISM1402-01

How do I connect a LAN Cable to a In-Sight Micro Series ISM 1402 Cognex Vision System ISM1402-01?
The In-Sight Micro Series ISM 1402 Cognex Vision System ISM1402-01 has the ability to connect to an Ethernet network. In order to do so, the LAN cable will be plugged into the I/O modules LAN port and proceed to connect the opposite end of the cable to a router/switch or PC.

What features of the In-Sight Micro Series ISM 1402 Cognex Vision System ISM1402-01 are unique to the 1402 specification?

One of the unique features of the ISM 1402 models is the sensor type, the specific sensor type typically used for this model is a 1/1.8-inch CMOS.

Reviews For ISM1402-01

Internal Review
(4.0)

Unfortunately, while this module is extremely useful to use in applications that are hard to reach if an item that is colorful must be read this device cannot accurately identify the item due to its lack of color bit-depth. - AX Control Tech Team
