ISM1403-10

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.00 (1)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.00 (1)
  • Click a star to rate this product
The Micro Vision System model ISM1403-10 is equipped with PatMax but does not have a color tool as other models with PatMax do. This unit has an I/O and PoE connector which are used for providing Ethernet connection and connection to the trigger input and high-speed outputs.
Request a Quote Request Repair
Request a Quote Request Repair

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a ISM1403-10 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: ISM1403-10
  • SKU: ISM140310CV
  • Manufacturer: Cognex Vision
  • Series: In-Sight Micro Series Vision System

ISM1403-10 Technical Specifications

Bit Depth 256 Grey Levels (8 bits/pixel)
Frames Per Second 14
Sensor Type 1/1.8" CCD
Storage Shock 80 G w/ 50 Gram or Lighter Lens
Supported Tools PatMax, ID, Essential, and Extended Tools
User Interface(s) Spreadsheet and EasyBuilder
Voltage 48 VDC
Weight w/o Mounting Block 121 g (4.27 oz)

About the ISM1403-10

In-Sight Micro Series Vision System unit ISM1403-10 is equipped with a PatMax tool set but does not have the color tool. There is also an extended tool feature which includes a caliper tool as well as a non-linear calibration tool which allows for the extension of PatMax. Some of the essential tools associated with this unit are image filters, standard calibration, curve, and line finding, as well as edge finding to name just a few of the many features. Other features included with the essential tools are found at the bottom of the Cognex In-Sight Micro Vision System Data Sheet which is attached above. This data sheet also provides information regarding the speed rating, acquisition, resolution, and potential user interfaces needed when operating this unit.

Another prime feature of using the ISM1403-10 model is its ability to be combined with a track and trace system. The track and trace system and in-sight vision systems being used together allow for the two to create a complete identification and data verification system solution when being used with pharmaceutical and medical device packages that have serialized labels.

This model was designed to be used in-stand alone features and is primarily used in factories that require a compact model to get into those hard-to-reach places to help inspect products to ensure that re-work and scrap will be diminished to not only save time for you and your company but money as well.

More specifications regarding the ISM1403-10 model can be found in the In-Sight Micro Series Installation Manual. This manual gives specifications regarding the cable types available to work with this model.

Frequently Asked Questions about ISM1403-10

What variables will affect the number of frames per second that the Cognex ISM1403-10 Compact In-Sight Micro Series Vision System is able to acquire.
The Cognex model specification will dictate the frames per second of the vision system. For example, the Cognex 1403 vision system has a maximum frames per second of 14 full frames per second. While this is the maximum potential frame/second of the specification number (ISM1403-10), this maximum id dependent on the job at hand. This dependency makes the assumption that there is not a user interface connection to the system at the time, and is based on the minimum exposure of a full frame capture with the acquisition trigger.
What is the power type for a Cognex ISM1403-10 Compact In-Sight Micro Series Vision System for factory floor measurement and identification?
The ISM1403-10 Compact In-Sight Micro Series Vision System has a class 2 power type using the Ethernet hooked to the PoE connection. The power type can be A and B, with a power consumption of 6.49 watt maximum consumption per PoE (class 2).
What type of voltage does the Cognex ISM1403-10 Compact In-Sight Micro Series Vision System receive?
The ISM1403-10 has a 48 VDC nominal voltage from a class 2 PoE connection (powered from a different voltage).

Reviews For ISM1403-10

Internal Review
(4.0)

While this model is enhanced with PatMax it does not have the color feature which enhances some models even more. The main difference between this model and some others with color is the lack of a color feature. - AX Control Technician
