Micro Vision System Model ISM1403-C10 is a 24-bit-depth color unit and has PatMax. The acquisition rate associated with this model is 7.5 fps. This model has an extended toolset which has a caliper and non-linear calibration tool.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a ISM1403-C10 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: ISM1403-C10
  • SKU: ISM1403C10CV
  • Manufacturer: Cognex Vision
  • Series: In-Sight Micro Series Vision System

ISM1403-C10 Technical Specifications

Acquistion Rate 7.5 fps
Color Model Yes, with PatMax
Features with ID Tool Set Text Reading and Verification, Image Filters, and 1D/2D Barcode Reading and Verification
Mounting Four M3 Threaded Mounting Holes
Resolution 1600 x 1200
Speed Rating 8x
Storage Temperature -22 to 176 °F
User Interface Spreadsheet and EasyBuilder

About the ISM1403-C10

Modeled as a Vision System produced by Cognex the ISM1403-C10 model is one of the many In-Sight Micro Systems. This is just one of the few models that have a color bit-depth which is denoted by the C within the part number. Another special feature of this model is that it has PatMax, typically models that have 10/C10 within their part number have the PatMax feature. There are two User Interfaces that can be used with this model which are either a Spreadsheet or EasyBuilder. As a 1403C model, this part is one of the higher-resolution models that can be used to inspect the smallest of defects as well as take precise measurements, which allows for the greatest accuracy.

Three different cables are associated with the operation of the ISM1403-C10 model, these cables are typically the ethernet cables, I/O modules cables, and breakout cables. There are several lengths associated with all of the cables, the typical cable lengths associated with the I/O module cable are two meters, ten meters, five meters, fifteen meters, and point seven meters. Please note that the I/O module cable will be used with the CIO-MICRO-CC or CIO-MICRO modules and can directly link the vision system and I/O modules by means of the DB15 connector.

There are two different ENET LEDs that are associated with the ISM1403-C10 model which are 10-BaseT or 100-BaseT, both of which are equivalent to each other and can detect network traffic, power, and establishment of network connection. Refer to the In-Sight Micro Series Vision System Installation Manual for extended information on the other LEDs and connector types on this unit.

Frequently Asked Questions about ISM1403-C10

What is the power type for the Cognex ISM ISM1403-C10?
The Cognex In-Sight Micro Series ISM1403-C10 vision system is a type A and B power option. The power consumption for this specification is 6.49 maximum W for the class 2 PoE, with current in agreement with the class 2 requirements. The voltage for the ISM1403-C10 Cognex is a 48 VDC voltage. The vision system receives this voltage through the PoE connection (class 2 PoE).
What specifications differentiate the Cognex ISM ISM1403-C10 from other Cognex vision systems?
The Cognex ISM ISM1403-C10 vision system is of the 1403 specification. This affords the unit with a minimum firmware requirement of 4.4.3. (In-Sight version). The sensor type for this vision system unique from other specifications is a 1/1.8 inch CCD with properties that are a 8.8 mm diagonal or a 4.4 by 4.4 pixel specification (micrometer sq.).
What is the maximum pixel resolution for a 1413 Cognex Vision ISM1403-C10 ISM In-Sight Micro Series Vision System?
The Cognex ISM1403-C10 In-Sight Micro Series Vision System has a maximum pixel resolution of 1600 x 1200. The Cognex 1412 specification on the other hand has a 1280 x 1024 maximum pixel resolution. The Cognex vision system 1500 has either a 640 x 480 or a 800 x 600 maximum pixel resolution.
