ISM1500-11

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
The ISM1500-11 model is one unit in the Cognex Vision In-Sight Micro Series System. This unit has a CS-Mount and C-Mount Lens with a 5 mm extension if desired. The firmware required to use this system is at minimum version 4.9.1.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a ISM1500-11 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: ISM1500-11
  • SKU: ISM150011CV
  • Manufacturer: Cognex Vision
  • Series: In-Sight Micro Series Vision System

ISM1500-11 Technical Specifications

Bit Depth 8 bits/pixel (256 Grey Levels)
Dimensions with Mounting Block 1.18" x 1.50" x 2.36"
Discrete Outputs 2; Opto-Isolated
Image Processing Memory 256 MB SDRAM
Nominal Voltage 48 VDC
Power Consumption Max. 6.49 W
Sensor Type 1/1.8" CMOS
Weight w/ Mounting Block 5.15 oz

About the ISM1500-11

Cognex Vision In-Sight Micro Vision System Model ISM1500-11 was designed as a Regulatory Model. When installing this model there are two primary connectors that are needed. The PoE and I/O Connector, each connector has a very specific function. For example, the I/O connector will be used to provide correspondence between the high-speed outputs and the acquisition trigger inputs. There are also three base light-emitting diodes on this system which are labeled LED1, LED2, and ENET. In relation to the ENET LED there are two types which are 10-BaseT and 100-BaseT. When power has initially been sent to a 10-BaseT LED the LED will be red to indicate that power has been detected, and will temporarily change to green when the network connection has been officially established.

The ISM1500-11 model has in-depth specifications regarding a variety of different things, for example, there is a specific electronic shutter speed, resolution, sensor types, bit depth, and even more. The electronic shutter speed that is used in regard to this model depends on the chosen resolution for which there are two, either 640 x 480 or 800 x 600; if the chosen resolution is 800 x 600 the shutter speed will be five microseconds to five-hundred milliseconds.

All of the above information regarding the ISM1500-11 camera can be found in the Cognex Vision In-Sight Micro Series Vision System Installation Manual. This manual gives more in-depth details about the installation and all of the proper specifications needed to operate this model. General purpose specifications can be found on pages eighteen to twenty.

Frequently Asked Questions about ISM1500-11

What do the LED indicators show on the back of a Cognex vision system such as a ISM1500-11?
The ISM1500-11 is similar to other Cognex vision systems in that the rear view shows two LED indicators below the I/O connector, with an ENET indicator below the LED indicators. Additionally there is a PoE connection at the lower right side of the unit. When LED1 is active there will be a green hue. This LED is able to be configured by the operator using the discrete output line 4 or line 10 if I/O modules are used (CIO-MICRO-CC or CIO-MICRO). Below LED1 is the LED2 indicator. This indicator is red when active. This indicator is user configurable using output line 5 (line 11 with the I/O modules mentioned above). Finally the ENET indicator has many color indications combined with either a flashing or a static indication.
With a 100-BaseT, this indicator in the lower left aspect of the Cognex vision system is red during startup when the unit is first receiving power. Then the indicator will be green as a network connection is established. When network traffic occurs the indicator will start blinking (green). If for some reason a connection had not occurred then the unit stays red.
