About the PA206V-133
The PA206V-133 is a Parker-Hannifin HMI unit. This unit is part of the company’s PA2 series of PowerStation HMIs that are specifically designed for use in challenging industrial environments. While this series is no longer available directly from the manufacturer, AX Control maintains an inventory of this unit.
The display on the PA206V-133 is a TFT VGA with a 640 x 480 resolution. It is an Active color HMI display with a brightness level of 350 NITS. The bulb life on this unit is rated at 75,000 hours. This unit can be operated on AC power if paired with an optional Parker AC power supply. Typically, the unit uses 24-volt input DC power. The unit can also be power by 12 or 24-volt input power. Applying AC power to the unit without the recommended AC power supply may result in damage to the unit.
The PA206V-133 has a viewing angle of 80/80 degrees left and right and 80/70 degrees up and down. This is a six-inch unit (5.7-inch diagonal.) The PA206V-133 is designed to withstand harsh environments. However, it should not be operated in locations where there are extreme levels of dust, moisture, oil, or corrosive vapors. Additionally, temperatures within the unit’s protective enclosure will likely be higher than ambient external temperatures. Be sure the unit is maintained at an operating temperature between 32 to 122 degrees Fahrenheit in non-condensing humidity levels of 5% to 95%.
Important additional information regarding maintenance and installation of the PA206V-133 can be found in Parker manuals and user guides.
