About the PA210T-135
The PA210T-135 is a 10.4-inch color touchscreen HMI made by Parker-Hannifin. It was originally part of the company’s PA2 family of PowerStation HMIs. This series was designed as a more advanced replacement for earlier PA HMIs and offered easy drop-in replacement capabilities with simple and fast clip mounting. The PA210T-135 is also a compatible replacement for many other older HMI designs. This unit has a 640 x 480 resolution (VGA).
The PA2 HMIs offer multiple standard features including
USB 2.0 Ports (2)
Serial Ports (2) (RS-232 and 1x configurable RS-232/RS422/RS485)
CompactFlash Storage
100BaseT Ethernet capability
Slim profile
Type 4/4X rating
Flexible connectivity options due to multiple communication drivers standard
Standard software features for graphics, networking, and alarming.
Optional software features for historical trending
Color TFT display with analog resistive touch panel
The PA210T-135 meets CE, UL/cUL, and Class 1 Div 2 specifications. It is designed to be used indoors only in an operating environment with a temperature between zero and 50 degrees Celsius. The unit is typically built using a ROM_DOS 6.11 OS and an AMD LX700 433 MHz central processor.
The PA210T-135 has a brightness level of 200 NIT and a bulb life of 50,000 hours. The unit weighs approximately 8.4 pounds before boxing. External dimensions are 11.00 x 13.78 x 4.01 inches.
Additional information about this unit including its power requirements, vibration and shock ratings, and detailed instructions for proper installation, can be found using original documentation from Parker. This includes user guides and manuals.
