193X257AAG01

About the 193X257AAG01

The 193X257AAG01 board was developed to function as a 20 volt power supply card. Designed by General Electric for the 193X board series, this card can be used as a replacement piece. When operated with a power supply rectifier and transformer, this card provides source power to the drive. Printed circuit cards and assemblies all receive their operational power supplies from this card.

Power supplies to the entire GE drive are dependent upon the 193X257AAG01 power supply card. Once combined with the supply rectifier and transformer, this card provides the board with +20 VDC and -20 VDC supplies. Outputs on the board are protected to only receive the maximum amount of voltage produced and a provided current of up to 750 mA. Fuses on the card operate in conjunction with one another. Should any fuse open, circuits on the opposite board face will force the other fuse to open as well.

Since this card is an integral component to overall board function, it is imperative that all provided installation parameters are met. Following these outlined guides will reduce the risk of any accidental or preventable device damages. The functionality of the entire drive is dependent upon proper installation. Only permit personnel who are trained and qualified to install drive boards to handle the 193X257AAG01 card. Wiring and installation instructions are provided to the user in the device’s corresponding manual and datasheet.

Our seasoned and trusted team at AX Control is happy to assist with any of your automation needs. Information regarding pricing or availability on 193X257AAG01, or any other part or repair, can be obtained by calling or emailing a member of our sales staff.
