193X475AAG01

About the 193X475AAG01

The 193X475AAG01 is a phase logic board. This is a type of printed circuit board or PCB. The 193X475AAG01 is a part of the 193x series by General Electric or GE.

The 193X475AAG01 is a long printed circuit board. This circuit card is rectangular in shape. Nineteen (19) integrated circuits are featured on the 193X475AAG01 printed circuit board. Twelve (12) of these integrated circuits are lined up on the left half of the 193X475AAG01 in four (4) rows of three (3) integrated circuits each. Seven (7) more integrated circuits are positioned on the 193X475AAG01 in two (2) parallel rows of four (4) and three (3), respectively. On the left half of the 193X475AAG01, there are six (6) small yellow capacitors lined up in a horizontal row. Two (2) more small yellow capacitors are paired up on the left edge of the 193X475AAG01. Two (2) small yellow capacitors are positioned on the lower right side of the 193X475AAG01 next to the row of integrated circuits. The last yellow capacitor is featured on the right side of the 193X475AAG01. This capacitor’s voltage, which is two-hundred volts (200V) is written on the outside of the component. Fifteen (15) small transistors which are black are positioned in rows on the top right side of the 193X475AAG01. Seven (7) of these are on the top row and the remaining nine (9) are on the bottom. Two (2) more black transistors are situated on the lower right side of the 193X475AAG01. Many small resistors, most of which are light blue with a series of colorful bands, are featured on the right of the PCB in rows.
