193X532ADG04

About the 193X532ADG04

The 193X532ADG04 is a field control card. This is a type of printed circuit board or PCB created by General Electric or GE. The 193X532ADG04 is a component in the 193x series by GE.

The 193X532ADG04 is a large printed circuit board with many components which may be small or large. The top half of the 193X532ADG04 is taken up by large components which are connected to the surface of the PCB with wires that are black or white. On the right side of this upper part of the board, there is a large metal plate. A large black plastic piece is attached to the metal plate which features three (3) fuses. These fuses are white with silver metal pieces on each end. Printed on the surface of the board below this are the words USE CARBONE FERRAZ FUSES TYPE A060FA-T13 OR EQUIVALENT 600 VOLTS 15AMP. Six (6) blue components which are shaped like squares are aligned along the bottom half of the right edge of the 193X532ADG04. These blue components are labeled as FMAX, CROSS, FMIN, FLOSS, SLIM, and ALIGN. Near the lower left corner of the 193X532ADG04, there is a large blue capacitor. This capacitor is positioned upright on the circuit board’s surface. Two (2) smaller black capacitors are sitting near the blue capacitor. Five (5) integrated circuits are located around the 193X532ADG04. These integrated circuits are small in size. Each features a collection of tiny components. These devices help to conserve space on the 193X532ADG04. The designators for many of these components are printed on the 193X532ADG04 in black writing.
