193X728ABG01

About the 193X728ABG01

The 193X728ABG01 is a GE PCB component for the GE DC Drives.  This includes the Speed Variator Drive and the SCR Drive. The SCR drive is a unidirectional drive that is a closed loop, adjustable speed system.  The Speed Variator Drive is also a closed loop adjustable speed system, but it is bidirectional.

The 193X728ABG01 has a connected blue/silver front panel.  This panel is connected to the board using screws threaded through drilled holes in a panel flange, through the PCB, to a reinforcing bar.   This panel is printed with the board number and name, and the General Electric logo. The panel has a single handle.

The 193X728ABG01 functions as a Signal Isolator card.  It provides electrical isolation of its output from its input. The board is populated with two toroidal transformers that are connected to the board by central screw mounts.  These components have wires that connect to the board. The first transformer has black, white, red, brown, orange, blue, yellow, and green wires. The second transformer has green, red, black and white wires.

The 193X728ABG01 has ten transistors, three polyester vinyl capacitors, and resistors made of metal film and carbon composite material.  Some components are numbered.

The 193X728ABG01 will be carefully packed by our warehouse team for shipment, including the use of an anti-static material.   Our team will help you determine the type and speed of shipping that will meet your needs. AX Control can ship anywhere around the globe, as long as the country is not currently under US Embargo.  Most in-stock products ordered before 4 pm EST will ship the same day.
