193X738ACG01

About the 193X738ACG01

The 193X738ACG01 is a GE PCB created as an oscillator board by General Electric for their DC drive systems like the Speed Variator Drive, the SCR Drive, and other compatible drives.    While both of these systems are closed loop, adjustable speed systems run by DC motors, there are some significant differences between them.  For example, the SCR drive is unidirectional, while the Speed Variator drive is bidirectional. Also, the SCR Drive is built with a separate operator station (a remote enclosure that includes the run/start control and the speed control, that provides basic command functions to the operator.)  This is not necessary for the Speed Variator Drive.

The 193X738ACG01 usually functions as a secondary or auxiliary board to another board.  Unlike many of the PCBs in the 193 series, it does not include a front panel. The 193X738ACG01 is a long narrow board with two holes drilled near the upper corners. It is populated with five transistors of two different designs. The board has nineteen metal film resistors on its surface.  Five of these are mounted horizontally. The rest are mounted vertically. The board has three polyester vinyl capacitors, with one capacitor mounted vertically. There are two diodes on the board.   All of these components have their locations marked on the board and carry a component number. The board identification number is located along the top edge of the board.

Our warehouse team will carefully pack the 193X738ACG01 for shipment to your facility, including the use of an anti-static sleeve to protect from static discharge during transit.
