531X113PSFAPG1

About the 531X113PSFAPG1

The 531X113PSFAPG1 is a large circuit board used for Turbine Control.  This particular board is a Power Supply Interface Card by General Electric.  The 531X113PSFAPG1 has eighty capacitors. The capacitors on 531X113PSFAPG1 store electrical energy in an electric field.  The 531X113PSFAPG1 has two hundred and fifty-six types of resistors. Resistors implement electrical resistance and are used when you need to reduce current flor, divide voltages, etc. In electronic circuits, resistors are used in a multitude of ways such as reducing current flow, adjusting signal levels, dividing voltages, bias active elements, and terminating transmission lines, among other uses. The 531X113PSFAPG1 has three inductors. Inductors store energy in a magnetic field as a current passes through them. The 531X113PSFAPG1 is a large circuit board with many pieces. The 531X113PSFAPG1 has nineteen integrated circuits. An integrated circuit is essentially the brains of the circuit board. They hold all the programming data for the circuit board to function. The integrated circuits are split into two groups referred to as EPROM and EEPROM. They are the same with one exception, the EPROM can be updated with new programming data while the EEPROM cannot.  The 531X113PSFAPG1 has two small blue boxes labeled AMP on the side. The top of these boxes is labeled OFF in the bottom left corner and has three white small buttons labeled one, two, and three. There are variable resistors on 531X113PSFAPG1 which can be identified as six small blue boxes with a white knob in the center.  To make adjustments on these you will need to use a screwdriver, in this way the potentiometer is set to allow potential passed through a circuit.

The staff at AX Control looks forward to answering any questions you may have. Give them a call today.
