531X121PCRACG1

About the 531X121PCRACG1

The GE Power Connection Board 531X121PCRACG1 is a renewal part for multiple original equipment power connection boards. The 531X121PCRACG1 contains jumpers that you must set before you install the board to match the voltages that the drive needs to operate. The board contains two jumpers that you must insert over the  pins to produce the specific voltages for the drive. Use your fingers or a needle-nose pliers to  insert the jumpers. Do not rest the jumpers on the board and make sure the jumpers are inserted securely. If the jumpers are lost inside the drive you must find the jumpers and install them before you start the drive.

If  you don’t set the jumpers correctly, you might damage the drive components or the incorrect voltages might result in unreliable operation of the drive. Be careful when you insert the jumpers over the pins that you do not bend the pins or touch other components on the board. Do not force the jumpers over the pins.

The 531X121PCRACG1 board is shipped in a container that is sealed to protect against tampering. Locate the label on the box before you open the box and check the model number and all serial numbers and all identifying information. Look for evidence that the box has been mishandled or that liquids have been spilled or leaked on the box. Having inspected the box, you can break the seal and open the container. Collect the manual and all other written material, for example, the printed warranty and service information and special instructions.
