About the 531X135PRGATM2

The 531X135PRGATM2 is a Programmer Board.  As the name implies, the board is used as part of a link in programming components in GE industrial systems.  531X135PRGATM2 is part of the GE 531X series of boards. The 531X135PRGATM2 has thirteen capacitors which store an electric charge.  The 531X135PRGATM2 has a large LED panel that will illuminate with numbers. The 531X135PRGATM2 has four sets of Jumper Ports. These Jumper Ports come with plastic covers that allow the worker to move them around the circuit board to control the flow of energy. The 531X135PRGATM2 has a crystal oscillator that uses crystals to make a highly precise frequency. The crystal oscillator creates an electrical signal and is best known in it’s usage in watches, as keeping time is generally the most frequent use of a crystal oscillator.

The 531X135PRGATM2 has a single small black transistor, this transistor is made of semiconductor material and normally features a three pronged design.  Transistors are crucial to modern electronics and are featured in everything from circuit boards to radios. The 531X135PRGATM2 has six Integrated Circuits that hold all the programs for the circuit board to function. The integrated circuits are the brains of the circuit board so to speak.  These circuits are also commonly known as chips and contain the data necessary for the board to perform its function.  These chips come in two varieties differing by their programmability.

This board has eighteen various colored resistors with banding marks which are used to determine energy restriction which is the main purpose of resistors.  The bands on 531X135PRGATM2 are colored and striped which will allow an someone versed in electrical circuitry to determine the use of each capacitor.
