The 531X144DRGAAG1 is a Diagnostic Readout Board

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a 531X144DRGAAG1 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 531X144DRGAAG1
  • SKU: GBTC-14167
  • Manufacturer: GE Boards & Turbine Control
  • Series: 531x Boards

531X144DRGAAG1 Technical Specifications

Manufacturer General Electric
Series 531x Boards
Part Number 531X144DRGAAG1
Board Type Diagnostic Readout Board

About the 531X144DRGAAG1

The 531X144DRGAAG1 daughterboard is a General Electric component designed to function as a Diagnostic Readout board. While this board is no longer manufactured or even supported by the original equipment manufacturer, AX Control works hard to maintain ready-to-ship stock of this component in both refurbished used and never-used surplus state. Please call or email to ask about our current inventory levels of either or both.

The 531X144DRGAAG1 is a small supplementary board designed to mount to the top of a CCHAP board using standoff connectors. Because this mounts to another board, the 531X144DRGAAG1 is a one-sided board. Factory-made holes are located along the board’s edges to allow for mounting.

The 531X144DRGAAG1 includes a line of six LED indicators. These are located along the right-hand side of the board and are labeled LED1 through LED6. Each LED corresponds to a resistor that is placed directly to its left.

Other board components include two vertical pin connectors, two integrated circuits, and two jumper switches. The jumpers are labeled ‘card test’ and ‘cell test.’ Additionally, the board has several other resistors, as well as diodes and capacitors. If you have questions about PCB components identification, refer to our extensive blog post for help.

Refer to General Electric manuals, data sheets, and user guides for more specific information regarding the use and operation of this equipment. As a static-sensitive board, the 531X144DRGAAG1 will be handled carefully by our team during packing and preparation for shipment. We recommend the use of a grounding strap during unboxing and any time you are handling the component. Make sure to read all installation instructions before unboxing your part.

AX Control typically ships out parts every day (M-F). Orders arriving before 3 pm usually leave our facility that day. Expedited shipping options are available for even faster turnaround times.

Frequently Asked Questions about 531X144DRGAAG1

What does the 531X144DRGAAG1 do?

The 531X144DRGAAG1 is a component that monitors and reports on various systems in the host drive.

How will the 531X144DRGAAG1 be packaged and shipped?

The 531X144DRGAAG1 will come in a static-protective sleeve and in a box to ensure no damage is done to the board.
