531X170TBSAAG1

About the 531X170TBSAAG1

The 531X170TBSAAG1 is a TB Option Board. The 531X170TBSAAG1 is a long narrow circuit board. The 531X170TBSAAG1 has minimal parts. The 531X170TBSAAG1 has four male ports and a female port to connect the 531X170TBSAAG1 into the existing setup. The 531X170TBSAAG1 has two red boxes with four white switches. Both sets of switches have the same sets of markings and labels for the switches. The first button is labeled one (1) C1, the second button is labeled two (2) C2, the third button is labeled three (3) C3, the fourth button is labeled four (4) C4. The 531X170TBSAAG1 has fifty-four screw-topped female ports in one row down the circuit board each with its own label. The screws are labeled as follows. 1- XSTP, 2-PCOM, 3-CTLNI, 4-CTLN2, 5-IMET, 6-REF24, 7-SLD5, 8-VMET, 9-FCMET, 10-PCN, 11- PCP, 12-MRI, 13-PFRF, 14-DTB, 15- DTB(with a line above the letters), 16-DTA, 17-DTA (with a line above the letters), 18-PREF, 19-PRFC, 20-IMET, 21-ACOM, 22-DCOM, 23-H232, 24-T232, 25-DM5, 26-K5A, 27-RXA, 28-PSPL, 29-DTRA, 30---, 31---, 32- CTSA, 33---, 34-TXA, 35---, 36- RX8, 37-DCOM, 38-DTRD, 39 +5V, 40-RST, 41-CTB, 42- + 5v, 43-TXS, 44-DCOM, 45-24v, 48-SPRNO, 49-START, 50- FDCM, 51-STOP, 52- MAXCM, 53-MAXNO, 54-MAXNC. The 531X170TBSAAG1 also has twenty-one screw ports next to the original line. The 531X170TBSAAG1 has one circular transistor. The 531X170TBSAAG1 has one toroidal core transformer which has a yellow core and red wire wrapped around it. The 531X170TBSAAG1 also has one Jumper Port.

If you would like a quote please reach out to AX Control via email or phone.
