531X170TBSADG1

About the 531X170TBSADG1

The 531X170TBSADG1 is a board component manufactured by GE to be used for general purpose drive systems from GE.  One of these systems is a DC-300 drive. Your user guide or manual should help you determine if the PCB is compatible with your drive system.

The 531X170TBSADG1 functions as a TB Option Card.  The board has dimensions of 2.75 inches by 11 inches.  It is designed with factory-made drill holes designed to allow for mounting options.  One mounting hole is located in each corner. Another is placed in the center of the board, and two are located on a board edge.

The 531X170TBSADG1 has two terminal strips.  One strip has fifty-four screw positions and the other has twenty-one screw positions.  Other components placed on the board include five connectors (three header connectors, a male vertical pin cable connector, and a female 37-pin DC connector,) an inductor coil, a relay, two switch components, a stab-on connector, a polyester vinyl capacitor, a jumper switch, and a diode.  The switch components each have four toggles. The relay component is marked “DS2E-M-DC24V.” This is a 2 Form C relay. It has epoxy resin seals and is suitable for use in difficult environments. It has gold-clad twin contacts that are highly stable and ensure stable contact resistance over time.  If more information is needed, please refer to GE manuals or data sheets that reference this part number.
