531X189LTBAJG1

About the 531X189LTBAJG1

The 531X189LTBAJG1 is a VA-5 Lan Option Card produced by General Electric. The 531X189LTBAJG1 has eight yellow rectangles called contactors, with the following written on the top: Aromat 00323, DS2E-M-DC24V-1C-H267, AG205444 J03. There are six male port that use ribbon harnesses to connect and communicate with other circuit boards. The 531X189LTBAJG1 has seven Jumper Ports. Each set of jumpers have three prongs and has two positions. There is one capacitor and three inductors. The inductors create a magnetic field that stores energy as it passes through the device. The inductors are also referred to as a coil, a choke or a reactor. The name varies depending on the manual you have but they are all the same thing. The 531X189LTBAJG1 also has sixty-six female ports with screws to secure various cables and wires. The ports are labeled as follows, they will be labeled with the number of the port first a dash and what the port label is.

1-K13-19CM, 2-K13NO/NC, 3-K14NO/NC, 4-K15NO/NC, 5-K16NO/NC, 6-K17NO/NC, 7-K18NO/NC, 8-K19NO/NC, 9-LI-1, 10-LI-2, 11-LI-3, 12-LI-4, 13-LI-5, 14-LI-6, 15-LI-7, 16-LI-8, 17-LI-9, 18-LI-10, 19-LI-11, 20-LI-12, 21-LI-13, 22-LI-14, 23-RSET, 24- +15V, 25-MSR, 26- -15V, 27-JOGR, 28-MUP1, 29-MUP2, 30-MUP3, 31-RUN, 32-JOG, 33-REF24, 34-POL, 35-XSTP, 36-CTLN1, 37-CTLN2, 38-IMET, 39-SLD5, 40-VMET, 41-FCMET, 42-PCN, 43-PCP, 44-DTM, 45-/DTM, 46-PFRF, 47-DTB, 48-/DTB, 49-DTA, 50-/DTA, 51-SMET, 52-DM5, 53-S5C, 54-S5NC, 55-S5NO, 56-SCCM, 57-R232, 58-T232, 59-PCOMX, 60-PCOMX, 61-PCOMX, 62-SPRNO, 63-SPRCM, 64-SPRNC, 65-CLA, 66-PSPL.

General Electric is the provider of all technical support in the form of instruction manuals and data sheets. The 531X189LTBAJG1 has now considered an obsolete part.

Call or email AX Control for more details.
