531X191RTBAEG2

About the 531X191RTBAEG2

General Electric developed the 531X191RTBAEG2 relay terminal card for the 531X board series. Members of this series are replacement boards, allowing them to be installed in a number of GE brand drives. This card provides users with access to a number of on board features. When installed, the terminal board provides seven relays that control external circuits. The card also allows users to access coils and contacts using the terminal board.

531X191RTBAEG2 provides users with useful board and drive functions. External circuits attached to the board can be controlled using this relay terminal card. Calculations for RTB points and relay contacts are also performed by this board. Internally, the card contains a 115 VAC coil that includes a 50/60 Hz. A number of indicator lights are also found on board. These integrated LED indicators provide visual cues to users of which relays are energized.

A number of manufacturer provided installation parameters are included with this board. Meeting these requirements will protect the overall integrity of the entire drive unit. Installation of the 531X191RTBAEG2 board should only be completed by qualified personnel trained to handle these cards. Installation and wiring instructions are available in the board’s manual as well as the datasheet. General Electric, the manufacturer of this board, was the original provider of technical support.

AX Control’s helpful and knowledgeable sales team is happy to help with all of your 531X191RTBAEG2 needs. Pricing for this board, as well as any other available part, can be obtained by contacting our office by phone or email.
