531X191RTBAFG4

About the 531X191RTBAFG4

The General Electric 531X191RTBAFG4 is a relay terminal board from the 531X replacement board series. Most drives across the GE brand are able to accept this card and rely on its functions. This board serves a dual purpose when installed in a drive. Seven relays are offered through the card to command externally connected circuits. Users can also use the terminal board to gain access to system integrated coils and contacts.

Capabilities of the card are useful features for the installed drive. When operating, the board can execute control functions for any external circuits attached to the seven relays. 531X191RTBAFG4 also works to tabulate RTB points and relays contacts. A G4 revision, coils and contacts for this card are rated for this section of the series. Coils for the board rate at 24 VDC ± 10%, or 37 mA. Contacts in this card have a current rated at 2.4 A and voltages rated at 125 VAC or 28 VDC. These contacts also feature a 1 mA per 0.1 V rating.

Board integrity is dependent upon users following all installation parameters outlined by General Electric. Only allow qualified personnel to handle and install these boards. Damages may result if boards are handled, installed, or wired improperly. A wiring guide for this card can be found in the 531X191RTBAFG4 relay manual and datasheet. General Electric, the manufacturer, was the original provider of technical support for the board.
