531X301DCCAJM1

About the 531X301DCCAJM1

The 531X301DCCAJM1 is a board component from General Electric.  This board was manufactured in conjunction with Fuji Co and is a FANUC component.  It is designed to fit within GE’s DC300 drive system and may be compatible with other general-purpose drive systems from General Electric.  These drives were created for industrial applications.

The 531X301DCCAJM1 is one of several DCCA boards available within this series. Please be sure you are ordering the correct replacement board for your needs to ensure compatibility with your particular system.

The 531X301DCCAJM1 is a large circuit board that is component dense.  Each mounted component is marked with a reference designation to help users with identification.  The board has over 80 integrated circuits.  This includes circuits that function as decoder/drivers, ones that function as analog operational amplifiers, and others that function as analog inverters.  The board also has a FPGA (field-programmable gate array.)

The 531X301DCCAJM1 is designed to accept auxiliary boards.  These mount to the board’s surface via screw connections and standoffs that are already mounted to the board’s surface.  Communication between the board and the auxiliary is accomplished through cable connections plugged into one of the many vertical pin connectors on the board’s surface.  The main board has been drilled in several locations to allow for mounting options.  It does not have a faceplate attached to any of its edges.

For additional information about the 531X301DCCAJM1, including detailed information regarding proper installation procedures, please refer to documentation from General Electic like manuals and user guides.  Technical support for this product was provided originally by the OEM.
