531X306LCCBDM2

About the 531X306LCCBDM2

The 531X306LCCBDM2 is a circuit board used in General Electrics drive systems. These systems original purpose was to be used in multiple industrial applications while being the most powerful and adaptable product on the market for the time. Now, this product is considered to be outdated and obsolete.

 The circuit board is considered a daughterboard and attaches to a larger circuit board to operate properly. To attach to the larger circuit board the 531X306LCCBEM2 uses four plastic pegs that allow the 531X306LCCBEM2 to sit on top of the larger circuit board. The 531X306LCCBEM2 also has two large black male connection terminals and two right-angled male terminal connectors as well. This circuit board may also be referred to as a LAN Communication board, or under the part number F31X306LCCBAG1.

The circuit board has a sixteen number LED panel. Each section has fourteen smaller sections that are used to make up any given number. The LED panel runs parallel to the left side of the circuit board, along with the short edge. The circuit board also features has six sets of jumper ports, various diodes, capacitors, resistors, transistors, and integrated circuits.

This circuit board also has various alpha and numeric markers to assist with installation.

General Electric has published multiple manuals, series user guides, data sheets that reference this circuit board number.

AX Control protects this circuit board with an anti-static bag along with proper padding during the shipping process. AX Control offers a wide range of shipping arrangements including expedited shipping.
