The F31X170TBSADG1 is a GE TB Option Card

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a F31X170TBSADG1 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: F31X170TBSADG1
  • SKU: F31X170TBSADG1GBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: 531x Boards

Product Description

F31X170TBSADG1--TB Option Terminal Board.

The F31X170TBSADG1 is a PCB component manufactured by GE.  This component is not for a specific system, but rather is a component for several general purpose drives including the DC-300.  While many of these drives are now considered obsolete, when they were originally released by GE they were considered powerful, dynamic systems able to perform many industrial tasks.  This board has an alternate board number of 531X170TBSAFG1.

The F31X170TBSADG1 has codes like 004/0, VA-5, 003/0, FR00/0, and 002/0. The main components on the board are two large terminal strips. The first of these runs the entire length of the F31X170TBSADG! and has fifty-four screw connections.  The second terminal strip has twenty-one screw connections. Each of these connections is labeled and numbered on the board surface, the first board along the bottom edge, and the second toward the top.

Other components located on the F31X170TBSADG1 surface include a rectifier diode, one jumper, a polyester vinyl capacitor, one inductor coil, a stab-on connector,  a relay, and two switch components that are placed side-by-side. The board also has both a female and a male cable connector along with three header connectors. The headers have 16, 9, and 24 pins, and are all vertical pin connectors.   The switch components each have four toggles on their top surface. These can be set to DCE or to DTE. The board has multiple factory-made drill holes placed along the board edges and in the corners.

More information about this board and its components, including installation instructions, can be found through GE publications (manuals, data sheets.)
