F31X171TMAAFG2

About the F31X171TMAAFG2

F31X171TMAAFG2--Terminal Board Relay Card

The F31X171TMAAFG2 is a replacement/renewal part manufactured by General Electric for use within some of their general purpose drive systems, like the DC-300, the AC-300, and the AC-500.

The F31X171TMAAFG2 is a long and narrow PCB that functions as a Micro Application TB Card.   It is marked with an alternate 531x number (531X171TMAAFS2,) and with codes like 002/0 and 006/0.

The F31X171TMAAFG2 is populated with three vertical pin header connectors.  This includes a 15-pin male header connector and two 24-pin male header connectors.  The board has three metal film resistors and three metal oxide varistors (MOVs.) Metal oxide varistors are typically used in AC power electronics circuits in order to protect against transient overvoltages.

The F31X171TMAAFG2  has three plug-in relay components.  These are located along the centerline of the board in a single line.  The last components on the board are three terminal strips; each of these is individually labeled and numbered along the bottom edge of the board.  This includes a 9-position terminal strip, a 24-position terminal strip, and a 54-position terminal strip. Some of these labels include 9-C10, 10-C11, 11-MAP1, 12-MAP2, 13-AN2, 79-K81CM, 80-K81NO, 81-K81NC, 82-K82CM, 83-K82NO, and 84-K82NC.

More information on the F31X171TMAAFG2 may be found through data sheets, manuals, and user guides from GE.   This includes information about maintenance, installation, and connections to other boards as well as the actual operation of the board.   General Electric was originally responsible for all of the technical support for this board component.
