F31X175SSBAKG2

About the F31X175SSBAKG2

The F31X175SSBAKG2 is a PCB component manufactured by GE as a component for their general purpose drive systems like the DC-300 drive.  GE general purpose drives a powerful, flexible system often used for industrial applications. Your system’s system manual or manufacturer user guide will help you determine if it is compatible with the 531x board series. Our team can also help with this.

Hardware Tips and Specifications

The F31X175SSBAKG2 functions as a Dual Channel BIU Series Six Interface board. It is marked with the board number. It also carries the number 531X175SSBASM2 and codes like 004/0, 005/0, and FR00/0. The board is factory drilled in all four corners and has notches cut out of both long edges. The series six board classification that this F31X175SSBAKG2 Dual Channel Interface Board printed circuit board product is often referred to has to be defined as a subseries classification of the original 531x Boards product series that this F31X175SSBAKG2 Dual Channel Interface Board device was truly intended for.

One long edge of the F31X175SSBAKG2 is populated by a multipin (male) connector. To the right of this is a notation on the board surface that states “Solder Direction” with an arrow that points to the right. The opposite long edge is populated by a toggle switch, two LED components, and thirty-six copper fingers. The F31X175SSBAKG2 is populated by three resistor network arrays, two switch components, over 45 jumpers, capacitors, resistors, and over fifty integrated circuits. This includes oscillating chips, high-performance analog magnitude comparators, and high-performance analog D flip-flops. The switch components on the board can be set to “on” or to “off.”  Most capacitors are made of ceramic material. Resistors are primarily made of metal film. More information about the board and its components may be found through publications from the manufacturer, like manuals, user guides, and data sheets.  These publications will also provide information on proper installation procedures.
