F31X189LTBAKG1

About the F31X189LTBAKG1

The F31X189LTBAKG1 is a board component designed and made by GE for use within various general purpose drive systems like the DC-300.  These drives are powerful, flexible systems typically used for industrial purposes. This board is part of the 531x series of boards. Please review your system’s paperwork (user guides/manuals) to establish compatibility with this board series.

The F31X189LTBAKG1 functions as a LAN Terminal Board Option Card.  The board is long and narrow and is marked with several codes including the alternate board number (531X189LTBA.)  It is also marked 006/01, 002/01, and 003/01. The board is factory-drilled in each corner and is drilled twice within the body of the board.

The F31X189LTBAKG1 has eight relays.  These are marked DS2E-M-DC24V-H300. These relays have gold-clad twin contacts, which allow for superior contact reliability and ensure extremely low contact failure rates.   The board has three coil inductors. It also has a single vertical pin cable connector (male) with twenty-six pins. The board has five vertical pin connectors from nine pins to twenty-four pins.

The F31X189LTBAKG1 has seven jumper switches.  It has a single capacitor made from polyester vinyl.  It has a single resistor made from metal film. The board has a single stab-on connector.   The board has three terminal strips. This includes a three position terminal strip, an eleven position terminal strip, and a fifty-two position terminal strip.  Each position on these strips is individually labeled with information like SCOM, R232, T232, PCOMX SPRNO, SPROM, SPRNC, CLA and PSPL (labels on the 11 position strip.)  More information on the board or functions of the board may be found through publications from GE such as manuals or data sheets.
