F31X307LTBAJG1

About the F31X307LTBAJG1

F31X307LTBAJG1--LAN I/O Terminal Board

The F31X307LTBAJG1 is a PCB component made by General Electric for several systems, including various general purpose drive systems like the DC-300 and the AC-300 drive.  These systems were originally created by GE for use in industrial settings for a wide variety of uses. This board is part of the 531x board series and carries a secondary number of 531X307LTBAJG1.  It is marked with codes like 003/0, 3295, CPC-1M, and 94V0. Some codes may be printed on the rear surface.

The F31X307LTBAJG1 communicates with other boards or off-board components using its multiple connectors.   This includes two male vertical pin cable connectors. There is a twenty pin and a twenty-six pin. There are two male header connectors and eight 2-position plug connectors.  The board also has fifteen terminal strips. Each of the terminal strips has three positions each. Eight of these strips is marked IN1 through IN8 and seven are marked OT1 through OT7.

Other components on the F31X307LTBAJG1 include seven relays, sixteen transistors, fifteen LED indicators,  and eight integrated circuits. The board also has diodes, metal film resistors and other resistors, capacitors made from electrolytic material and of ceramic material, and thermistors.  Board components are marked with reference designators for easy identification.

The F31X307LTBAJG1 has two standoffs.  These are located on one edge and in the center of the board.  Corners are factory drilled. One edge is marked for alignment.   Please use publications from the original equipment manufacturer like data sheets, user guides, and manuals to access more information about this board like installation procedures and operation information.
