Exciter Simplex Backup Module IS200ESBPG1A is produced by GE in the EX2100 series. This board has thirteen backplane connectors built into the board. This board also has a total of nine female plug connectors.

Request a Quote Request Repair

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a IS200ESBPG1A to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: IS200ESBPG1A
SKU: IS200ESBPG1AGBTC

Manufacturer: GE Industrial Systems
Series: EX2100 Excitation Control

Description
Repairs
Warranty
Manuals

IS200ESBPG1A Technical Specifications

Alphanumeric Catalog Number	IS200ESBPG1A
Board Description	Exciter Simplex Backup
Functional Acronym/Abbreviation	ESBP
Number of Female Plug Connectors	Nine
Quantity of Backplane Connectors	13
Quantity of Vertical Pin Ribbon Connectors	5

About the IS200ESBPG1A

The IS200ESBPG1A model is an Exciter Simplex Backup Model. The model is typically connected to a backplane model and does so through thirteen backplane connectors which are in four groups on the model. Pertaining to the group orientation there are three groups of three and one group of four. On one side of the board in a single line, there are five vertical ribbon connectors, these connectors are known as male connectors, all of these connectors vary in size and how they function.

There are nine female plug connectors on the IS200ESBPG1A board, all of the plugs are of varying sizes. On the bottom half of the board, in the middle, there are five sub-d connectors. From left to right they are named J504 EACF, J505 EXTB, and EXHS, J405 ECTB, J305 EPCT, and J7 Bridge. The purpose of these connectors is to be able to connect with other models and boards within the EX2100 system.

This board is no longer in production at General Electric but can still be found on the market and especially here at AX Control INC. We have both new and used surplus from our large inventory, for more information you can contact us by phone or email.

Frequently Asked Questions about IS200ESBPG1A

What boards connect to the IS200ESBPG1A model?

There is only one section on the ESBP backplane, which contains the power supply for the EPSM model. Within controller M1 the DSPX, ACLE, EMIO, EROC, ESEL, and EISB boards are connected.

Some of the backplanes within the EX2100 Series need to be cooled, does the ESBP require cooling?

Yes. The ESBP backplane model requires one overhead fan to cool the controller.

What type of circuit board is the ESBP model?

The ESBP model is a control board.

There are typically two modes that all of the EX2100 Series is used in, redundant or simplex. Which mode is the ESBP backplane used in?

The ESBP backplane model is only used in simplex mode applications.
