IS200MVRCH1A Image One
3 year warranty

❯

IS200MVRCH1A Image 1
IS200MVRCH1A Image 2
IS200MVRCH1A Image 3
IS200MVRCH1A Image 4
visa card logo american express logo master card logo bbb logo duns seal

About | Product Specifications | FAQs

IS200MVRCH1A

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (4)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (4)
  • Click a star to rate this product
The IS200MVRCH1A from Series EX2100 is developed by General Electric Industrial Drives as a component made for the larger Mark V and VI system C cores.
Request a Quote Request Repair
Request a Quote Request Repair

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a IS200MVRCH1A to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: IS200MVRCH1A
  • SKU: IS200MVRCH1AGBTC
  • Manufacturer: GE Industrial Systems
  • Series: EX2100 Excitation Control

IS200MVRCH1A Technical Specifications

# of Mounting Holes 8 for Base and 4 for HSLA
# of Ports 15
Abbreviation MVRC
Manual GEH-6731E
Revisions Available IS200MVRCH1ACA
Weight Less than 3 lbs.

About the IS200MVRCH1A

Part of the EX2100 series from General Electric the IS200MVRCH1A model is used as an Analog Input-Output board. This board will be the baseboard for the IS210MVRCH1A PWA Assembly. The best way to achieve this is by connecting the MVRC board to the High-Speed Serial Link Board IS200HSLAH1A.

There are fourteen ports on the IS200MVRCH1A board which are used to connect a variety of different cables, some of the ports are labeled as JDD, JAR, JAT, JBB, and even more. There are no potentiometers on the board thus indicating that calibration is not necessarily required when working with this board.

Some boards within the EX2100 series have LEDs used to indicate faults and errors as well as power, the IS200MVRCH1A does not have any LEDs that can be used for indication which is one of the reasons why this board will need to be connected with other models from this series. The best manual to use with this board is the GEH-6731E.

If you would like to purchase the IS200MVRCH1A board or check its availability, please contact AX Control’s sales department for pricing information as well as shipping times. Contact the sales department by phone at (919) 372–8413 or by email at sales@axcontrol.com for this information.

Reviews For IS200MVRCH1A

Internal Review
(4.0)

This board would be a 5+ star product, however, the 10+-year-old plastic cable clips have been found to snap easily, being a cause for loose or faulty connections. - AX Control Inc. Tech

Repair Services For IS200MVRCH1A

Type Lead Time Price Action
Repair Service 1-2 weeks $1800

Our highly skilled technicians can repair your IS200MVRCH1A. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More

IS200MVRCH1A Manuals, White Papers, Data Sheets, and Troubleshooting
