About the DS3800DFXX1B1B
The DS3800DFXX1B1B is a circuit board module part within the Mark IV turbine control system. The Mark IV is just one of the Speedtronic systems created by General Electric for the management and control of industrial gas and steam turbine systems, as evidenced through its full extended series name as the Mark IV Turbine Control System Series. The Mark IV increased its reliability through the use of a new architecture (TMR) while maintaining low costs through a modular design. With this being known, this DS3800DFXX1B1B device's greater Mark IV Turbine Control System Series is separately seen as an attractive product series on its greater general automated industrial marketplace given the fact that it is one of General Electric's final-developed Mark product series to make use of the patented Speedtronic control system technology first witnessed with the rollout of the initial Mark I Series in the mid to later 1960s. The Mark IV Series that this DS3800DFXX1B1B device is a component member of is no longer actively being manufactured by General Electric, as it exists as a now-obsolete legacy product series in its current form.
Hardware Tips and Specifications
The DS3800DFXX1B1B board functions as an interface board that allows the system to connect to an outside network. This is done directly through ribbon connectors. The ribbon connectors on this board are located on the long board edges, with two on one edge and one on the other edge. The board has seven jumper pins located in a single line near the middle of the board. If you are replacing a current board, you should note your current jumper settings and duplicate them on your replacement board. Other board components include a single potentiometer, three test points, integrated circuits, resistors, transistors, and capacitors. Most components are marked with some sort of reference designator and may also carry their original manufacturer code. General Electric manuals and user guides will help you with installation and will help you better understand the different codes written on the board’s surface. These codes should give you additional information regarding wiring and the proper positioning of the board. AX Control is located in Raleigh, NC within the Research Triangle. We provide quality industrial automation replacement parts to customers close by and customers around the world. If you are local to our facility please feel free to send your courier to us for faster service. It is currently unknown whether or not this DS3800DFXX1B1B product is the original product of its intended functionality, although its eccentric DS3800DFXX1B1B functional product number's trailing alphanumeric digits would seem to indicate as much. This DS3800DFXX1B1B product featured here does not make use of any VME Rack-minded front-facing installation faceplate, instead relaying on a series of factory-drilled holes in its base printed circuit board for installation purposes. Each one of these mentioned factory-drilled holes should have been ringed with an insulated material, because of the possibility of damaging surface voltages existing.
Given the fact that the DS3800DFXX1B1B modular assembly was originally manufactured for a now-obsolete legacy product series, this DS3800DFXX1B1B device is not surrounded online by any great amount of originally-pertinent instructional manual materials. With this being the case, the DS3800DFXX1B1B functional product number itself can be treated as a decent supplementary source of DS3800DFXX1B1B Board hardware component and component specification information, as it codes for an embedded set of DS3800DFXX1B1B Board details through a series of consecutive functional naming segments. For example, the DS3800DFXX1B1B functional product number starts off with a dual-functional naming segment in the DS3800 series tag indirectly delegating this DS3800DFXX1B1B Board's special modular Mark IV Series assembly as well as its domestic original manufacture location. Some of the other relevant hardware specifications revealable through use of the DS3800DFXX1B1B functional product number include this DS3800DFXX1B1B Mark IV Series printed circuit board product offering's:
- DFXX functional product abbreviation
- Group one Mark IV Series product grouping
