DS3800HCMC1A1B

About the DS3800HCMC1A1B

The GE Gas Turbine Daughter Board DS3800HCMC1A1B features a modular connector for attachment to a drive and retention levers to hold the board in the drive. The GE Gas Turbine Daughter Board DS3800HCMC1A1B also is populated with 14 jumpers, and 1 amber and 2 red indicator LEDs. The board also has 2 34-pin connectors, and multiple capacitors and resistors.

The indicator LEDs on the board are situated so that while the board is installed in the drive rack, the operator can see the LEDs at a glance. The LEDs are located between the 2 34-pin connectors. When 1 or both of the red LEDs are lit, it indicates that an error has occurred. When the amber LED is lit, it indicates that a warning has been issued. For more information about the error and warnings, you can run the diagnostic tools available on the drive.The tools provide a history of the drive activity and details about the performance of the components. For example, if any errors have occurred, you can read the report and learn when the error occurred and learn the cause of the error.

The diagnostic tools also includes any trip conditions. Trip conditions are situations that might damage the drive. Some trip conditions are caused by an overheating situation. That is, heat has built up in the interior of the drive. This can happen if the room the drive is installed in is too hot. It can also happen if the heat in the drive cannot escape due to blocked air vents.
