DS3800HHTB1D1D

About the DS3800HHTB1D1D

General Electric (GE) created the DS3800HHTB1D1D printed circuit board (PCB). This circuit board was made for the Speedtronic Mark IV (MKIV) series for turbine control. The Speedtronic Mark series have evolved over several decades from the earliest Mark system, MKI, to MKII and later to the MKIV system. The Mark systems have been in charge of controlling, regulating, and maintaining the safety of both turbines and the people who operate them since the creation of the MKI in 1968. The MKIV system is the product of years of the refinement of industrial automation techniques.

The DS3800HHTB1D1D features 34 integrated circuits. Each integrated circuit contains a variety of very small electronic devices such as capacitors, transistors, and resistors all on one chip. Many banded pink resistors and banded blue resistors are located in various places throughout the board. Several yellow capacitors can also be found on the DS3800HHTB1D1D. Three red LEDs or light-emitting diodes can be seen on the right side of the DS3800HHTB1D1D. There are four test points positioned under these three LEDs. These test points allow an operator to test the circuit board for any problems. One long black connector port occupies the left half of the DS3800HHTB1D1D. There are two large silver diodes positioned on the left half of the DS3800HHTB1D1D. The product’s full name, DS3800HHTB1D1D 6BA05, is printed at the bottom of the circuit board
