About the DS3800HLIA1A1B
This DS3800HLIA1A1B printed circuit board product offering from General Electric was originally specifically designed and manufactured for the Mark IV Turbine Control System Series, as was delegated in the DS3800HLIA1A1B brief product description provided just above for your ease of research. This DS3800HLIA1A1B device's greater Mark IV Series, as you have more than likely been able to predict based off of its full extended series name, has a series of specific applications in the control systems and management systems of popular General Electric-compatible gas and steam turbine automated drive assemblies. This has to be considered something of a downgrade when compared to soon-to-come Mark product series iterations such as the Mark VI Turbine Control System Series, as this future series' possible intended applications additionally include alternative energy-based wind turbine control and management systems as well. The Mark IV Turbine Control System Series containing this DS3800HLIA1A1B device is additionally considered a now-obsolete legacy GE product series, given the fact that it was discontinued due to a series-wide functional obsolescence in one of the many years beyond its initial rollout. This DS3800HLIA1A1B product's greater Mark IV Series is still very much attractive on its greater figurative promotional marketplace, as it is one of General Electric's final-developed Mark product series to incorporate the patented Speedtronic control system technology into a wide range of different options.
Hardware Tips and Specifications
The retention levers serve as the locking mechanism to hold the board in the rack. They keep the modular connectors fully seated and keep the board from moving. When the drive is in operation, the operator can keep track of the board by viewing the LEDs. The LEDs are located at the front of the board and so are viewable while the drive is processing signals and the motor is receiving power. When the amber LED is lit, the board is receiving power and all diagnostic startup tests have been passed. If the red LEDs are flashing, it indicates that the board is active and processing information. If the red LEDs are not flashing, it might indicate that an error has occurred and processing has stopped. If you suspect a problem with the board, you might remove all power from the drive and pull up on the retention levers to remove the board from the rack. Then wait a few seconds and return the board to the rack and insert the board back into the modular connector. Lock the board by pressing the retention levers. Restore power to drive and monitor the board activity to verify that processing activity has restarted.
The GE Div Multi Auxiliary Board DS3800HLIA1A1B is designed for quick installation in the drive. The board features a modular connector on 1 end and retention levers on the other end. The GE Div Multi Auxiliary Board DS3800HLIA1A1B also is populated with 15 red indicator LEDs and 1 amber LED which are visible from the front of the board. Whole this DS3800HLIA1A1B device's installation and replacement procedures are certainly important to realize before making any final purchase decision, their placement on this DS3800HLIA1A1B personalized product page here is truly more reminiscent of this DS3800HLIA1A1B device's lack of online-available originally-printed instructional manual materials than it is of their crucial nature. With this being the case, the DS3800HLIA1A1B functional product number can be identified as a decent primary source of DS3800HLIA1A1B Board hardware component and component specification information, as it codes for many of these details through its characteristic series of functional naming elements. For instance, the DS3800HLIA1A1B functional product number begins with a rendition of the dual-functional DS3800 series tag considered important as it indirectly asserts this DS3800HLIA1A1B PCB's domestic original manufacture location on top of its normal Mark IV Series assembly version. Some of the other relevant hardware details embedded in the DS3800HLIA1A1B functional product number itself include this HLIA-abbreviated product's:
- HLIA functional product abbreviation
- Group one Mark IV Series grouping
